Java 接入 AI 大模型个人实践：多轮对话与流式输出实现

三、流程及表结构设计思考

1. 设计思考

基于上述代码逻辑，实现连续对话需解决以下问题：

1. 历史存储：必须将对话历史存储在本地数据库，以便构建上下文。
2. 会话控制：需要控制会话的生命周期，包括上下文 Token 限制和会话超时时间。

基于以上两点，设计两张数据表：一张用于存储用户提问 (chat_question_history)，另一张用于存储模型回复 (chat_answer_history)。新增 session_id 属性用于关联同一时间段内的连续对话。

2. 表结构设计

两表通过 question_id 关联，确保一问一答对应。使用 user_id 和 session_id 区分不同用户的会话历史。

CREATE TABLE `chat_answer_history` (
  `id` varchar(50) NOT NULL COMMENT '主键 id',
  `user_id` bigint NOT NULL COMMENT '用户 id',
  `session_id` varchar(30) NOT NULL COMMENT '会话 id',
  `question_id` bigint NOT NULL COMMENT '问题 id',
  `answer` longtext CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci NOT NULL COMMENT '答案',
  `message_role` varchar(30) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL COMMENT '角色',
  `message_tool_calls` varchar(30) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL,
  `message_tool_call_id` varchar(64) DEFAULT '',
  `message_name` varchar(64) DEFAULT '',
  `create_time` datetime DEFAULT NULL COMMENT '创建时间',
  `create_by` varchar(255) DEFAULT NULL COMMENT '创建者',
  PRIMARY KEY (`id`),
  KEY `session_id_index` (`session_id`) USING BTREE,
  KEY `question_id_index` (`question_id`) USING BTREE,
  KEY `user_id_index` (`user_id`) USING BTREE
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci COMMENT='答案历史对话表';

CREATE TABLE `chat_question_history` (
  `id` bigint NOT NULL AUTO_INCREMENT COMMENT '主键 id',
  `user_id` bigint NOT NULL COMMENT '用户 id',
  `session_id` varchar(30) NOT NULL COMMENT '会话 id',
  `question` longtext CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci NOT NULL COMMENT '问题',
  `question_file_name` varchar(30) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL COMMENT '文件名称',
  `question_file_url` varchar(30) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL COMMENT '文件地址',
  `model` varchar(30) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL COMMENT '模型类型',
  `assistant` varchar(30) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL COMMENT '定义模型方向',
  `create_time` datetime DEFAULT NULL COMMENT '创建时间',
  `create_by` varchar(255) DEFAULT NULL COMMENT '创建者',
  `message_role` varchar(10) CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_ai_ci DEFAULT NULL COMMENT '角色',
  PRIMARY KEY (`id`),
  KEY `session_id_index` (`session_id`) USING BTREE,
  KEY `user_id_index` (`user_id`) USING BTREE
) ENGINE=InnoDB AUTO_INCREMENT=215 DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci COMMENT='提问历史对话表';

四、多轮对话 + 流式输出代码实现

1. Maven 依赖配置

确保项目中包含 DashScope SDK 及相关 Web 依赖。

<dependency>
    <groupId>com.alibaba.dashscope</groupId>
    <artifactId>dashscope-sdk-java</artifactId>
    <version>latest</version>
</dependency>
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-webflux</artifactId>
</dependency>

2. 请求接口 Controller

使用 Spring WebFlux 的 Flux 处理流式响应，避免阻塞线程。

import com.alibaba.dashscope.aigc.generation.GenerationResult;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.http.MediaType;
import org.springframework.web.bind.annotation.*;
import reactor.core.publisher.Flux;

@RestController
@RequestMapping("/chat")
public class ChatController {

    @Autowired
    private IChatQuestionHistoryService questionHistoryService;

    /**
     * 获取 AI 返回结果（流式）
     */
    @PostMapping(path = "/getChat", produces = MediaType.TEXT_EVENT_STREAM_VALUE)
    public Flux<GenerationResult> gptChat(@RequestBody ChatQuestionVo chatQuestionVo) {
        return questionHistoryService.gptChat(chatQuestionVo);
    }

    /**
     * 历史对话列表
     */
    @GetMapping("/historyList")
    public TableDataInfo historyList() {
        // 分页查询逻辑
        Long userId = SecurityUtils.getUserId();
        List<ChatHistoryVo> list = questionHistoryService.historyList(userId);
        list.sort(Comparator.comparing(ChatHistoryVo::getCreateTime));
        return getDataTable(list);
    }
}

入参 VO 定义：

@Data
public class ChatQuestionVo {
    private String question;
    private String sessionId;
    private String model;
    private String assistant;
    private String questionFileName;
    private String questionFileUrl;
}

3. 接口实现 Service

Service 层负责调用 SDK、管理会话状态及持久化数据。

@Service
public class ChatQuestionHistoryServiceImpl implements IChatQuestionHistoryService {
    @Autowired
    private ChatQuestionHistoryMapper chatQuestionHistoryMapper;
    @Autowired
    private ChatAnswerHistoryMapper chatAnswerHistoryMapper;

    @Value("${chat.accessKeyAli}")
    private String accessKeyAli;

    @Override
    public Flux<GenerationResult> gptChat(ChatQuestionVo question) {
        StringBuilder contentBuilder = new StringBuilder();
        Constants.apiKey = accessKeyAli;
        Generation gen = new Generation();

        Long userId = SecurityUtils.getUserId();
        String username = SecurityUtils.getUsername();

        // 会话管理：新建或检查超时
        if (StringUtils.isEmpty(question.getSessionId())) {
            question.setSessionId(String.valueOf(System.currentTimeMillis()));
        } else {
            long sessionTime = Long.parseLong(question.getSessionId());
            if (System.currentTimeMillis() - sessionTime > 5 * 60 * 1000) {
                question.setSessionId(String.valueOf(System.currentTimeMillis()));
            }
        }

        // 加载历史消息
        List<Message> messages = conversationHistory(question.getSessionId());
        messages.add(Message.builder().role(Role.USER.getValue()).content(question.getQuestion()).build());

        GenerationParam param = buildGenerationParam(messages);

        return Flux.create(sink -> {
            try {
                gen.streamCall(param, new ResultCallback<GenerationResult>() {
                    @Override
                    public void onEvent(GenerationResult message) {
                        String newContent = message.getOutput().getChoices().get(0).getMessage().getContent();
                        contentBuilder.append(newContent);

                        // 判断是否结束
                        if ("stop".equals(message.getOutput().getChoices().get(0).getFinishReason())) {
                            saveHistory(history, answerHistory, userId, username, question, message, contentBuilder);
                            contentBuilder.setLength(0);
                        }
                        sink.next(message);
                    }

                    @Override
                    public void onError(Exception err) {
                        sink.error(err);
                    }

                    @Override
                    public void onComplete() {
                        sink.complete();
                    }
                });
            } catch (Exception e) {
                sink.error(e);
            }
        });
    }

    private void saveHistory(ChatQuestionHistory history, ChatAnswerHistory answerHistory,
                             Long userId, String username, ChatQuestionVo question,
                             GenerationResult message, StringBuilder contentBuilder) {
        // 保存问题记录
        ChatQuestionHistory qHistory = new ChatQuestionHistory();
        BeanUtils.copyProperties(question, qHistory);
        qHistory.setUserId(userId);
        qHistory.setCreateBy(username);
        qHistory.setMessageRole(Role.USER.getValue());
        qHistory.setCreateTime(new Date());
        chatQuestionHistoryMapper.insertChatQuestionHistory(qHistory);

        // 保存回答记录
        ChatAnswerHistory aHistory = new ChatAnswerHistory();
        aHistory.setId(message.getRequestId());
        aHistory.setAnswer(contentBuilder.toString());
        aHistory.setUserId(userId);
        aHistory.setSessionId(question.getSessionId());
        aHistory.setQuestionId(qHistory.getId());
        aHistory.setMessageRole(message.getOutput().getChoices().get(0).getMessage().getRole());
        aHistory.setCreateBy(username);
        aHistory.setCreateTime(new Date());
        chatAnswerHistoryMapper.insertChatAnswerHistory(aHistory);
    }

    private GenerationParam buildGenerationParam(List<Message> messages) {
        return GenerationParam.builder()
                .model(ChatModelConstants.Models.QWEN_MAX)
                .messages(messages)
                .resultFormat(GenerationParam.ResultFormat.MESSAGE)
                .topP(0.8)
                .incrementalOutput(true)
                .build();
    }

    private List<Message> conversationHistory(String sessionId) {
        List<Message> messages = new ArrayList<>();
        if (StringUtils.isEmpty(sessionId)) {
            return messages;
        }
        // 查询最近 10 条记录作为上下文
        messages = chatAnswerHistoryMapper.conversationHistory(SecurityUtils.getUserId(), sessionId);
        return messages;
    }

    @Override
    public List<ChatHistoryVo> historyList(Long userId) {
        return chatQuestionHistoryMapper.historyList(userId);
    }
}

4. Mapper SQL 查询

使用 UNION ALL 合并问题和回答记录，按时间排序取最新 N 条。

<select id="conversationHistory" resultType="com.alibaba.dashscope.common.Message">
    SELECT
        content,
        role
    FROM
        (
            SELECT
                question AS content,
                message_role AS role,
                create_time
            FROM
                kim_chat_question_history
            WHERE
                user_id = #{userId}
              AND session_id = #{sessionId}
            UNION ALL
            SELECT
                answer AS content,
                message_role AS role,
                create_time
            FROM
                kim_chat_answer_history
            WHERE
                user_id = #{userId}
              AND session_id = #{sessionId}
        ) AS combined_data
    ORDER BY
        create_time
    LIMIT 10
</select>

<select id="historyList" resultType="com.kingoffice.system.domain.vo.ChatHistoryVo">
    SELECT
        t1.question,
        t1.id AS questionId,
        t1.create_time AS createTime,
        t2.answer,
        t2.id AS answerId
    FROM
        kim_chat_question_history t1
            INNER JOIN kim_chat_answer_history t2 ON t1.id = t2.question_id
    WHERE
        t1.user_id = #{userId}
    ORDER BY
        t1.create_time DESC
</select>

五、总结与后续优化

至此，后端已实现多轮对话以及流式输出功能。代码中仍有一些待完善的地方，例如对于 Token 数量的精确控制、参数校验、会话时长管理等都是需要考虑的问题。

此外，SpringAI 组件和阿里微服务组件提供了更快速的大模型调用方案，感兴趣的同学可以深入研究。后续计划在前端部分展示如何调用后端流式接口，实现 SSE 实时渲染效果。

配置示例 (application.yml)

chat:
  accessKeyAli: your_api_key_here
  timeout: 30s

注意事项

1. Token 限制：实际生产中需计算输入输出 Token 总数，防止超出模型限制。
2. 异常处理：网络波动或 API 错误时需有重试机制。
3. 安全性：API Key 应存储在环境变量或配置中心，严禁硬编码。
